State Machine

Activity Description

Provides modeling logic in the form of a state machine workflow, using which modeling can be streamed in an event-driven manner, in which only two active components, the state flow and the final state flow, can be placed

Attribute Description

This activity has no input/output properties

Execution steps: Place different state flows (initial state flow must be connected to [start]) - Set conditions between each state flow (multiple branches can be set at the same time) - Place final state flow to terminate the state machine
